HEAVY DUTY
Magnetic Drilling Machines

TV.120

Drills up to Ø 120 mm · 4-speed gearbox

The TV.120 is ToolVisor's heavy-duty magnetic drill, taking annular cutters to Ø 120 mm in plate up to 200 mm thick on an MT-4 Morse-taper spindle. A four-speed gearbox spanning 35–500 rpm matches surface speed to cutter diameter, and a 22,000 N magnetic base holds the machine solid through the deepest cuts.

Get a Quote → View Specs ↓
TV.120
Ø 12–120 mm (0.47–4.72″)
Annular Cutters
22,000 N (≈4,950 lbf)
Magnetic Force
2000 W
Motor Power
TECHNICAL SPECIFICATIONS

Technical Data

Annular Cutters
Ø 12–120 mm (0.47–4.72″)
Twist Drills
Ø 6–49 mm
Threading
M8–M42
Countersinking
Ø 10–50 mm
Magnetic Force
22,000 N (≈4,950 lbf)
Motor Power
2000 W
Total Power
2200 W
Speed (RPM)
  • 30-90 (Gear 1)
  • 90-160(Gear 2)
  • 160-270(Gear 3)
  • 270-500(Gear 4)
Spindle
MT-4
Power Supply
  • 220–240 V AC
  • 50/60 Hz (110 V version on request)
Length
450 mm
Width
160 mm
Height
520–780 mm
Stroke
260 mm
Weight
34 kg (75 lb)
KEY FEATURES

What Makes It Stand Out

Drilling Capacity
  • Annular cutters up to Ø 120 mm
  • Twist drilling to Ø 49 mm
  • MT-4 Morse-taper spindle
Four-Speed Gearbox
  • 35–90 rpm for large-diameter cutters
  • 90–160 and 160–270 rpm mid range
  • 270–500 rpm for small cutters and drills
Stability
  • 22,000 N magnetic base
  • 260 mm stroke
  • Plastic chip guard fitted as standard
SCOPE OF SUPPLY

In the Box

  • Magnetic drilling machine
  • Carrying case
  • Safety strap-retaining chain
  • Coolant bottle & lubrication hose
  • Allen-hex key set
  • Arbor MT4-19.05mm
  • Arbor MT4-31.75mm
  • Drill chuck 16mm
  • Carbon brush set
  • Plastic chip guard
  • Operating manual & warranty card
WORKS WITH

Compatible

  • TCT annular cutters Ø 12–120 mm
  • HSS annular cutters Ø 12–120 mm
  • MT-4 arbor / cutter adaptor
  • Twist drill 49mm
  • Machine Tap M12 to M42 + Tapping Arbor
  • Pilot pins
  • Cutting lubricant
GET IN TOUCH

Enquire About
TV.120

Fill in your details and our team will get back to you within 24 hours (Mon–Sat, IST / GMT+5:30) with pricing and availability.

Response within 24 hours
Dedicated support team
India & worldwide delivery
WhatsApp Us
ALSO IN MAGNETIC DRILLING MACHINES

Related Products

TV.40
TV.40
Drills up to Ø 40 mm · 1050 W motor
Ø 12–40 mm (0.47–1.57″) Ø 6–13 mm (Weldon) 1050 W
View Details →
TV.60T
TV.60T
Drills up to Ø 60 mm · M3–M24 tapping
Ø 12–60 mm (0.47–2.36″) Ø 6–32 mm M3–M24
View Details →
TV.40H
